PIE 830 Multifunction Process Calibrator

Product Overview: PIE 830 Multifunction Process Calibrator

PIE 830 Carry eight single function calibrators plus a milliamp calibrator with loop supply in the palm of your hand!

PIE 830 Features



•  Lighten up your toolbox

 Compact calibrator replaces toolbox of single function devices:

 Milliamp • Voltage • Frequency • pH • Thermocouples • RTDs • Pressure • Troubleshooter

•  First multifunction calibrator with three troubleshooting tools

Troubleshoot loop problems – Quickly diagnose ground fault and current leakage with patented Loop Diagnostic technology.

Automatically detect 2, 3 or 4 wire RTDs – Trouble shoot sensor connections and find broken wires with patented technology.

Troubleshoot wiring problems – Beep with continuity checker.

•  Simulate pH probes & calibrate pH transmitters

 Source from 0.000 to 14.000 pH @ 25 degrees C (77 degrees F) into transmitters & analyzers corresponding to -414.12 to +414.12 mV

•  Technician friendly operation

Intuitive EZ-DIAL Double Click Menu makes it easier to setup than other multifunction calibrators. Same as the single function PIE Calibrators.

•  Calibrate 2 wire transmitters – control input & monitor output

 Simulate transmitter inputs while powering it with the internal isolated 24 V supply & measuring the 4-20 mA output. Dual display of transmitter input & output. Simplify HART hookups with built-in 250 Ohm resistor

•  Use it as a milliamp and voltage calibrator

 Source 0 to 24.000 mA, 0 to 10.250 V dc, -20.000 to 99.999 mV and -500.00 to 999.99 mV. Read to 24.000 mA, 60.00 V dc -99.999 to +99.999 mV and -999.99 to +999.99 mV. Simulate 2-Wire Transmitters.

•  Calibrate directly in temperature to 0.1 degrees C & 0.1 degrees F

 Compatible with the instruments you use including all brands of smart transmitters and PLCs with 14 thermocouple & 9 RTD types.

•  Checkout flow & vibration systems

 To 2000 CPM (Counts-Per-Minute), 999.99 Hz, 9999.9 Hz & 20.000 kHz.

•  Measure pressure with optional pressure modules

32 modules for gauge, differential, absolute & compound pressure



•  Easy to read

Turn on the backlight & easily see the display in dark areas of the plant

•  Quickly set any three outputs plus automatic stepping & ramping

Easily set any value quickly with the adjustable ‘DIAL’ plus store any three output settings for instant recall with the EZ-CHECK™ switch. Choose between 2, 3, 5 & 11 steps to automatically increment the output in 100%, 50%, 25% or 10% of span. Select RAMP to smoothly increase and decrease the output between Zero and Span. Set step/ramp time to match your system from 5, 6, 7, 8, 10, 15, 20, 25, 30 and 60 seconds.

•  Measure temperature sensors, frequency pickups, loop currents, voltage levels & pressures

Check the values of your process sensors. Instantly recall MAX and MIN values to see process variability
